chainflex® CF211.PUR data cable

1 of 3

Item no.

CF211.PUR.02.01.02

Number of cores and conductor nominal cross-section

(2x0.25)C

Outer diameter (d) max. mm [mm]

chainflex® CF211.PUR data cable PUR

Typical application areas

For heavy duty applications
Almost unlimited resistance to oil
Indoor and outdoor applications with average sun radiation
Unsupported travel distances and up to 100 m for gliding applications
Machining centres / machine tools, storage and retrieval systems, packaging industry, handling, refrigerating areas

Guaranteed lifetime according to guarantee conditions
More Information: [Link id="13"]

Double strokes*					5 million	7.5 million	10 million
Temperature,	v max. [m/s]		a max.	Travel distance	R min.	R min.	R min.
from/to [°C]	unsupported	gliding	[m/s2]	[m]	[factor x d]	[factor x d]	[factor x d]
-25 / -15					10	11	12
-15 / +70	5	3	50	≤ 100	7.5	8,5	9,5
+70 / +80					10	11	12

* Higher number of double strokes possible - please ask for your individual calculation.
